Understanding the Function of Shell & Tube Heat Exchangers Shell & tube heat exchangers use a bundle of tubes within a shell to transfer heat between two fluids. Iconography can simplify their design: a shell symbol for the outer casing, parallel lines for the tube bundle, and arrows to show fluid flow. These icons make understanding the heat transfer process easier, highlighting efficiency and functionality visually and engagingly. https://courtneyandnye.com/
